Taïga
”The Taïga is a worthy adventure bike through and through. It is perfectly set up for some trail shredding straight out of the box.” Read the complete review HERE.
In between a trail bike and a multi-day adventure bike, the Taïga has multi purposes. In fact, the Taiga has recently been the bike of choice for participants in the Silk Road Mountain Race, the long-distance mountain bike race considered to be the toughest in the world.
The small front triangle provides ample clearance for maneuvering more difficult terrain. Combined with a long dropper seatpost, wide tires and suspension fork, the Taiga lends itself wonderfully to trail riding. For bikepacking outings on rougher trails, consider the rigid fork, narrower tires and long top tube bag to maximize storage space.
Our selection of Reynolds 725 tubing gives this frame just the right amount of suppleness and responsiveness, while keeping the weight reasonable. A 67deg steering angle and 75deg seat angle strike a balance between modern and progressive geometry, without falling into an overly radical design. The 437mm rear center distance offers a centered position on the bike (front-center versus rear-center ratio), and can be increased for even greater stability when a rear rack is used.
* The frameset (carbon fork) comes with wheel axles, headset installed, seatpost collar and frame protectors.
Pickup available at Vélo-Cité
Usually ready in 5+ days
Sizing guide - Taiga
Riding with a well-fitted bike is key to comfort, performance and fun! Contact us for any technical questions you may have. Complete geometry chart can be found on this page.
| SMALL | MEDIUM | LARGE | |
|---|---|---|---|
| APPROXIMATIVE CYCLIST HEIGHT | 5’1’’ – 5’6’’ | 5’6’’ – 5’10’’ | 5’10’’ – 6’2’’ |
Product information
We're proud to offer products for which every detail has been thought through and validated.
We offer a warranty that covers the owner of a Panorama bike for life. First of all, should a manufacturing issue arise, this defect will typically surface quickly in the life of the bike. That's why we offer a full 5-year warranty against manufacturing defects. Then, if an accident, fall or impact causes damage to the frame, you'll be covered by our lifetime crash replacement policy. Simply return the frame to us, and we'll assess whether repair is possible or replacement is necessary, at the lowest possible cost.
Return the bike after 10 days of testing if anything is not up to your expectations. Your satisfaction (and especially your fun outdoor) is at the top of our priorities. See the Terms of Sale for more information.
Head over here if you want to learn more about the values and vision behind Panorama Cycles products.
We know you want your order as soon as possible! We will ship your box once the order is confirmed, and be sure the product you ordered will be carefully wrapped to protect it during shipment.
We use flat rates for all of Canada and the United States. This rate will be displayed at the time of payment for your purchase. Custom duties are included in the purchase price for US shipment.
For international purchases, please contact us prior to placing your order so that we can send you the best possible shipping rate. The prices varies quite a lot depending of the region. for complete bike, the cheapest way to ship the bike in parts (not assembled) in 2 boxes.
As an example, here are some ball-park rates for shipping to Europe (again please contact to validate the exact rate to the final destination):
Frameset: 200-350$CAD
Complete bike in parts: 450-700$CAD
Complete bike assembled: 700-950$CAD
Visit or contact one of our key partner in order to know if they currently have in stock the model and size that you are looking for.
Panorama Taïga
MULTIFUNCTION TRAIL GEOMETRY
Modern geometry offering the fun and performance of a hardtail trail bike, combined with above average long-distance off-road adventure capabilities.
Main Features
REYNOLDS 725 TUBESET
Frame made with a bespoke selection of Reynolds 725 tubes. Tubes are thinned in the right places to provide the comfort and enjoyment of riding a steel frame without the extra weight.
SLIDING REAR DROPOUTS
Adjustable sliding dropouts which are ideal for adapting the ride feel of the bike, or for use in single speed configuration or with a Rohloff hub.
MULTIPLE MOUNTS
Ready to be equipped for a short or long bikepacking outing with its many mounts: triple mounts on downtube, cargo cages on the carbon fork, top tube bag and rear rack mounts.
TAPERED HEAD TUBE AND CHOICE OF FORK
Lightweight carbon fork with a length equivalent to a 120mm suspension, or a suspension fork.
INTERNAL SURFACE TREATMENT
The internal surface of the frame is treated by electrodeposition. This additional step in the finishing of the frame helps to ensure better protection against corrosion.
TIRE CLEARANCE
The frame has generous clearance to accommodate 29¨x 2.8¨ tires.
PELLVETICA X PANORAMA CYCLES
Vancouver based artists (and cyclists) Pellvetica signs the visual of the frame.
INTERNAL CABLE ROUTING FOR DROPPER POST
Seat tube opening in order to accommodate internal cable routing for an adjustable seat post.
The story behind
At the Core
A sectional view of planet Earth, showing the silouhettes of each of its layers. A creation of the duo Pellvetica.
This illustration is part of Panorama Cycles’ commitment to do its part for the environment. Find out more now:
Specifications
All our bikes are assembled at our factory in Granby, Canada, so we offer some customization options. Those options provide the best balance between reliability and weight.
Weight of assembled bike, medium size: approx 28 lbs, depending on options chosen.
You want to customize your bike by replacing a few parts? Send us your wish list and we will be pleased to answer your request.
Frame
INTERNAL CABLE ROUTING FOR DROPPER SEAT POST
SLIDING DROPOUTS – SINGLE SPEED / ROLHOFF COMPATIBLE
SRAM T-TYPE (UDH) DROPOUT INSERT AVAILABLE
POST MOUNT BRAKE STD
REAR RACK MOUNT
TRIPLE WATER BOTTLE MOUNT UNDER AND ON TOP OF THE DOWNTUBE
GAS TANK MOUNT ON TOP OF TOP TUBE
ELECTRODEPOSITION SURFACE TREATMENT (CORROSION PROTECTION)
12MMX148MM BOOST REAR SPACING
73mm BSA BOTTOM BRACKET
TAPERED 1-1/2¨ x 1-1/8¨ HEAD TUBE
DIA 34.9MM SEAT POST CLAMP
DIA 31.6MM SEAT POST
HEADSET: TOP ZS44 LOWER ZS56
MAXIMUM TIRE CLEARANCE: 29¨X2.8¨; 27.5¨X3¨
Fork
OPTION 1: 100% CARBON
TRIPLE CARGO CAGE MOUNTS
15MMX110MM BOOST SPACING
TAPERED STEER TUBE 1-1/8¨ / 1-1/2¨
MAX TIRE CLEARANCE : 29¨X3.0¨; 27.5¨X3.25¨
500mm LENGTH (120mm SUSPENSION FORK EQUIVALENT AT 25% SAG)
OPTION 2: MARZOCCHI BOMBER Z2, 120MM, BLACK (130mm fork available on request)
Components
| Wheels | OPTION 1: WTB STi30 / SHIMANO TC500 (FRONT) / TC600 (REAR), 32 HOLES, CENTERLOCK, MICROSPLINE OPTION 2: HUNT TRAIL WIDE MTB, CUSTOM BUILT FOR PANORAMA CYCLES WITH 32 SPOKES |
| Tires | MAXXIS REKON, 29X2.6, EXO/TR, 60TPI, TANWALL |
| Brakes | OPTION 1: SRAM LEVEL T OPTION 2: SHIMANO XT 4 PISTONS M8120 |
| Rotors | SRAM CENTERLINE 180MM OR SHIMANO RT-70 |
| Crankset | RACE FACE AEFFECT, 32T, CHAINRING |
| Bottom Bracket | RACE FACE BSA TEAM |
| Cassette | OPTION T1: SRAM PG-1230 11-50T OPTION T2: SHIMANO M6100 12SPD 10-51T OPTION T3: SHIMANO M7100 12SPD 10-51T |
| Chain | KMC X12 |
| Rear derailleur | OPTION T1: SRAM NX EAGLE OPTION T2: SHIMANO M7100 SLX OPTION T3: SHIMANO M8100 XT |
| Shifter | OPTION T1: SRAM NX EAGLE OPTION T2: SHIMANO M7100 SLX OPTION T3: SHIMANO M8100 XT |
| Handlebar | OPTION 1: RITCHEY MTN Comp 10D Rizer, 31.8x800mm, 20mm rise, 10D backswept OPTION 2: RACE FACE CHESTER 35MM, 35MM RISE, 780MM |
| Stem | OPTION 1: RITCHEY MTB trail, Alloy BBK 31.8X45mm OPTION 2: RACE FACE RIDE, 35MM, 50MM X 6DEG |
| Headset | FSA NO.57E |
| Seatpost | DROPPER POST KS E20I (100mm, 125mm or 150mm depending on frame size) |
| Saddle | WTB PURE |
| Pedals | Not included |
Geometry
Who this bike is for:
- You're looking for a versatile mountain bike for both trail riding and off-road bikepacking
- You're an ultra off-road racer, and want a comfortable, durable bike for long days in the saddle.
Not exactly what you are looking for?
You are looking for a mountain bike designed to be used with dropbars? Take a look at the Taïga EXP.
You want a bike that fits tires larger tires than 2.8''? Take a look at the Torngat Ti.
Riding with a well-fitted bike is key to comfort, performance and fun! Contact us for any technical questions you may have.
geometry chart
| SMALL | MEDIUM | LARGE | |
|---|---|---|---|
| APPROXIMATIVE CYCLIST HEIGHT | 5’1’’ – 5’6’’ | 5’6’’ – 5’10’’ | 5’10’’ – 6’2’’ |
| STANDOVER HEIGHT | 680mm | 715mm | 750mm |
| HEAD TUBE ANGLE | 67° | 67° | 67° |
| SEAT TUBE ANGLE | 75° | 75° | 75° |
| STACK | 602mm | 612mm | 621mm |
| REACH | 430mm | 449mm | 476mm |
| HEAD TUBE LENGTH | 100mm | 110mm | 120mm |
| SEAT TUBE LENGTH | 390mm | 425mm | 460mm |
| HORIZONTAL TOP TUBE LENGTH | 591mm | 613mm | 642mm |
| CHAINSTAY LENGTH | 437mm (min) | 437mm (min) | 437mm (min) |
| BB DROP | 65mm | 65mm | 65mm |
| FORK RAKE/OFFSET | 51mm | 51mm | 51mm |
| WHEELBASE | 1146mm | 1169mm | 1200mm |
| TRAIL | 105mm | 105mm | 105mm |
| STEM LENGTH | 45mm | 45mm | 45mm |
On The Media
“ The Taïga is an exceptional bike that lines up closely with a few other steel hardtails available. It’s balanced and comfortable to ride on a variety of surfaces, including technical trails, and is specced accordingly. ” Read the complete review here.
Bike Gear Database
“ It really rides exactly as it should for its intended uses, and it’s always a blast. ”Read the complete review here.
high quality assembly
How to unbox your new bike
If you live too far from one of our certified dealer, we will gladly ship the bike to your door. Each bike is completely assembled and tuned prior to be carefully packaged.
